TC-3500

PID Temperature Controller

  • Description: PID Temperature Control
    Operating Voltage: 12-24 VDC
    Switching Current: 7 AMPS Max.
    Ambient Temperature Range: 0 °C to 50 °C, 30 to 95 percent RH non-condensing
    [fileaway base=”5″ only=”tc-3500 data sheet.pdf”]

    Overview:
    The TC-3500 temperature controller series simplifies your temperature control requirements.
    This controller reduces system complexity and set up cost. The TC-3500 is a high performance PID temperature
    controller in space-saving, panel-mount size. RS485 with MODBUS-RTU (JBUS) protocol and IP 65 mounted in panel with gasket suitable for wide range of environments.
    For use with reverse polarity capable air conditioners and cold plates.

  • MODEL NUMBERPART NUMBERSWITCHING
    VOLTAGE VDC
    MAX. SWITCHING
    CURRENT AMPS
    SENSOR (included)COMMUNICATIONS
    TC-350035-44S-30-000
    12-247PTC ThermistorNone
    TC-350035-44S-32-000
    12-247PTC ThermistorRS-485
  • Click to open files:
    [fileaway base=”4″ sub=”tc-3500-drawings”] [fileaway base=”5″ only=”tc-3500 data sheet.pdf”]
  • Product manual & documentation:

    [fileaway sub=”tc-3500″]

Features:
• Control PID double action
• PID functions AUTO TUNING FAST, SELF TUNING, FUZZY OVERSHOOT CONTROL
• Multi Set Point Up to 4 programmable set points
• Overall accuracy +/-0,5% full scale (TC S :+/- 1% fs)
• Unit of measurement °C / °F, programmable
• Max. cold junction compensation drift 0,1°C/°C with operating temperature 0…50°C after warm-up time of 20 min.
• Sampling rate 8 sample per second
• Serial communication RS485 with MODBUS-RTU (JBUS) protocol
• Communication rate 1200…38400 baud, programmable
• Display 4 red digit h=12 mm
• Parameters access Protected by password
• Operating temperature 0…50°C
• Operating humidity 30…95 RH% without condensation
